DCM™ DC-DC Converter Module
High power converters for all standard industry input voltages
The DCM ChiP is an isolated, regulated DC-DC converter, operating from an unregulated, wide range input to generate an isolated output. With its high frequency zero voltage switching (ZVS) topology, DCMs consistently deliver high efficiency across their specified input line range. Modular DCM converters used independently or with downstream point of load (PoL) products support efficient power distribution, providing superior power system performance and connectivity from a variety of unregulated power sources to the point of load. Options include a family of DCMs with tighter output voltage regulation. The DCM VIA module provides a higher level of functionality with integrated EMI filtering, tight output voltage regulation and a secondary-referenced control interface.
Learn more about how DCMs are being used to power world changing innovations, such as how the Vicor DCM3623 powers the leading hybrid-electric aircraft.
Filter Products
0 Products
Viewing
of
###
25
of
| Part Number | Datasheet | Input (V) | Output (V) | Power (W) | Control Interface | Optimized for | Mounting | Temperature | Dimensions mm | Dimensions in. | Package | Add to cart / view details | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Part Number: | Input (V): 24.0 (18.0 - 36.0) |
Output (V): 5.0 (4.0 - 5.5) |
Power (W): 180.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 24.0 (18.0 - 36.0) |
Output (V): 5.0 (4.0 - 5.5) |
Power (W): 180.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 24.0 (18.0 - 36.0) |
Output (V): 12.0 (7.2 - 13.2) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 24.0 (18.0 - 36.0) |
Output (V): 12.0 (7.2 - 13.2) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 24.0 (18.0 - 36.0) |
Output (V): 15.0 (9.0 - 16.5) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 24.0 (18.0 - 36.0) |
Output (V): 15.0 (9.0 - 16.5) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 24.0 (18.0 - 36.0) |
Output (V): 24.0 (14.4 - 26.4) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 24.0 (18.0 - 36.0) |
Output (V): 24.0 (14.4 - 26.4) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 24.0 (18.0 - 36.0) |
Output (V): 28.0 (16.8 - 30.8) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 24.0 (18.0 - 36.0) |
Output (V): 28.0 (16.8 - 30.8) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 24.0 (18.0 - 36.0) |
Output (V): 36.0 (21.6 - 39.6) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 24.0 (18.0 - 36.0) |
Output (V): 36.0 (21.6 - 39.6) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 24.0 (18.0 - 36.0) |
Output (V): 48.0 (28.8 - 52.8) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 24.0 (18.0 - 36.0) |
Output (V): 48.0 (28.8 - 52.8) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 28.0 (16.0 - 50.0) |
Output (V): 3.3 (2.97 - 3.63) |
Power (W): 120.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 28.0 (16.0 - 50.0) |
Output (V): 3.3 (2.97 - 3.63) |
Power (W): 120.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 28.0 (16.0 - 50.0) |
Output (V): 3.3 (2.97 - 3.63) |
Power (W): 120.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 28.0 (16.0 - 50.0) |
Output (V): 3.3 (2.97 - 3.63) |
Power (W): 120.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 28.0 (16.0 - 50.0) |
Output (V): 5.0 (4.0 - 5.5) |
Power (W): 180.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Chassis Mount |
Temperature: -40 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
Package: 3414 VIA |
View Details | ||
| Part Number: | Input (V): 28.0 (16.0 - 50.0) |
Output (V): 5.0 (4.0 - 5.5) |
Power (W): 180.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Board Mount Short Pin |
Temperature: -20 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
Package: 3414 VIA |
View Details | ||
| Part Number: | Input (V): 28.0 (16.0 - 50.0) |
Output (V): 5.0 (4.0 - 5.5) |
Power (W): 180.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Chassis Mount |
Temperature: -20 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
Package: 3414 VIA |
View Details | ||
| Part Number: | Input (V): 28.0 (16.0 - 50.0) |
Output (V): 5.0 (4.0 - 5.5) |
Power (W): 180.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Chassis Mount |
Temperature: -55 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
Package: 3414 VIA |
View Details | ||
| Part Number: | Input (V): 28.0 (16.0 - 50.0) |
Output (V): 5.0 (4.0 - 5.5) |
Power (W): 180.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Board Mount Long Pin |
Temperature: -55 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
Package: 3414 VIA |
View Details | ||
| Part Number: | Input (V): 28.0 (16.0 - 50.0) |
Output (V): 5.0 (4.0 - 5.5) |
Power (W): 180.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Board Mount Short Pin |
Temperature: -55 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
Package: 3414 VIA |
View Details | ||
| Part Number: | Input (V): 28.0 (16.0 - 50.0) |
Output (V): 5.0 (4.0 - 5.5) |
Power (W): 180.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Board Mount Short Pin |
Temperature: -40 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
Package: 3414 VIA |
View Details | ||
| Part Number: | Input (V): 28.0 (16.0 - 50.0) |
Output (V): 5.0 (4.0 - 5.5) |
Power (W): 180.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Board Mount Long Pin |
Temperature: -40 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
Package: 3414 VIA |
View Details | ||
| Part Number: | Input (V): 28.0 (16.0 - 50.0) |
Output (V): 5.0 (4.0 - 5.5) |
Power (W): 180.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Board Mount Long Pin |
Temperature: -20 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
Package: 3414 VIA |
View Details | ||
| Part Number: | Input (V): 28.0 (16.0 - 50.0) |
Output (V): 5.0 (4.0 - 5.5) |
Power (W): 180.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 28.0 (16.0 - 50.0) |
Output (V): 5.0 (4.0 - 5.5) |
Power (W): 180.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 28.0 (16.0 - 50.0) |
Output (V): 5.0 (4.0 - 5.5) |
Power (W): 180.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 28.0 (16.0 - 50.0) |
Output (V): 5.0 (4.0 - 5.5) |
Power (W): 180.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 28.0 (16.0 - 50.0) |
Output (V): 12.0 (7.2 - 13.2) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Board Mount Long Pin |
Temperature: -40 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
Package: 3414 VIA |
View Details | ||
| Part Number: | Input (V): 28.0 (16.0 - 50.0) |
Output (V): 12.0 (7.2 - 13.2) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Board Mount Long Pin |
Temperature: -20 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
Package: 3414 VIA |
View Details | ||
| Part Number: | Input (V): 28.0 (16.0 - 50.0) |
Output (V): 12.0 (7.2 - 13.2) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Board Mount Short Pin |
Temperature: -20 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
Package: 3414 VIA |
View Details | ||
| Part Number: | Input (V): 28.0 (16.0 - 50.0) |
Output (V): 12.0 (7.2 - 13.2) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Chassis Mount |
Temperature: -20 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
Package: 3414 VIA |
View Details | ||
| Part Number: | Input (V): 28.0 (16.0 - 50.0) |
Output (V): 12.0 (7.2 - 13.2) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Board Mount Short Pin |
Temperature: -40 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
Package: 3414 VIA |
View Details | ||
| Part Number: | Input (V): 28.0 (16.0 - 50.0) |
Output (V): 12.0 (7.2 - 13.2) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Chassis Mount |
Temperature: -40 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
Package: 3414 VIA |
View Details | ||
| Part Number: | Input (V): 28.0 (16.0 - 50.0) |
Output (V): 12.0 (7.2 - 13.2) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Chassis Mount |
Temperature: -55 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
Package: 3414 VIA |
View Details | ||
| Part Number: | Input (V): 28.0 (16.0 - 50.0) |
Output (V): 12.0 (7.2 - 13.2) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Board Mount Long Pin |
Temperature: -55 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
Package: 3414 VIA |
View Details | ||
| Part Number: | Input (V): 28.0 (16.0 - 50.0) |
Output (V): 12.0 (7.2 - 13.2) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Board Mount Short Pin |
Temperature: -55 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
Package: 3414 VIA |
View Details | ||
| Part Number: | Input (V): 28.0 (16.0 - 50.0) |
Output (V): 12.0 (7.2 - 13.2) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 28.0 (16.0 - 50.0) |
Output (V): 12.0 (7.2 - 13.2) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 28.0 (16.0 - 50.0) |
Output (V): 12.0 (7.2 - 13.2) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 28.0 (16.0 - 50.0) |
Output (V): 12.0 (7.2 - 13.2) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 28.0 (16.0 - 50.0) |
Output (V): 15.0 (9.0 - 16.5) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Chassis Mount |
Temperature: -40 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
Package: 3414 VIA |
View Details | ||
| Part Number: | Input (V): 28.0 (16.0 - 50.0) |
Output (V): 15.0 (9.0 - 16.5) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Board Mount Long Pin |
Temperature: -40 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
Package: 3414 VIA |
View Details | ||
| Part Number: | Input (V): 28.0 (16.0 - 50.0) |
Output (V): 15.0 (9.0 - 16.5) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Chassis Mount |
Temperature: -20 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
Package: 3414 VIA |
View Details | ||
| Part Number: | Input (V): 28.0 (16.0 - 50.0) |
Output (V): 15.0 (9.0 - 16.5) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Board Mount Short Pin |
Temperature: -55 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
Package: 3414 VIA |
View Details | ||
| Part Number: | Input (V): 28.0 (16.0 - 50.0) |
Output (V): 15.0 (9.0 - 16.5) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Board Mount Long Pin |
Temperature: -55 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
Package: 3414 VIA |
View Details | ||
| Part Number: | Input (V): 28.0 (16.0 - 50.0) |
Output (V): 15.0 (9.0 - 16.5) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Chassis Mount |
Temperature: -55 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
Package: 3414 VIA |
View Details | ||
| Part Number: | Input (V): 28.0 (16.0 - 50.0) |
Output (V): 15.0 (9.0 - 16.5) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Board Mount Short Pin |
Temperature: -20 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
Package: 3414 VIA |
View Details | ||
| Part Number: | Input (V): 28.0 (16.0 - 50.0) |
Output (V): 15.0 (9.0 - 16.5) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Board Mount Long Pin |
Temperature: -20 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
Package: 3414 VIA |
View Details | ||
| Part Number: | Input (V): 28.0 (16.0 - 50.0) |
Output (V): 15.0 (9.0 - 16.5) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Board Mount Short Pin |
Temperature: -40 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
Package: 3414 VIA |
View Details | ||
| Part Number: | Input (V): 28.0 (16.0 - 50.0) |
Output (V): 15.0 (9.0 - 16.5) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 28.0 (16.0 - 50.0) |
Output (V): 15.0 (9.0 - 16.5) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 28.0 (16.0 - 50.0) |
Output (V): 15.0 (9.0 - 16.5) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 28.0 (16.0 - 50.0) |
Output (V): 15.0 (9.0 - 16.5) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 28.0 (16.0 - 50.0) |
Output (V): 24.0 (14.4 - 26.4) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Board Mount Short Pin |
Temperature: -40 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
Package: 3414 VIA |
View Details | ||
| Part Number: | Input (V): 28.0 (16.0 - 50.0) |
Output (V): 24.0 (14.4 - 26.4) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Board Mount Short Pin |
Temperature: -55 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
Package: 3414 VIA |
View Details | ||
| Part Number: | Input (V): 28.0 (16.0 - 50.0) |
Output (V): 24.0 (14.4 - 26.4) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Chassis Mount |
Temperature: -55 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
Package: 3414 VIA |
View Details | ||
| Part Number: | Input (V): 28.0 (16.0 - 50.0) |
Output (V): 24.0 (14.4 - 26.4) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Board Mount Long Pin |
Temperature: -55 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
Package: 3414 VIA |
View Details | ||
| Part Number: | Input (V): 28.0 (16.0 - 50.0) |
Output (V): 24.0 (14.4 - 26.4) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Chassis Mount |
Temperature: -20 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
Package: 3414 VIA |
View Details | ||
| Part Number: | Input (V): 28.0 (16.0 - 50.0) |
Output (V): 24.0 (14.4 - 26.4) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Chassis Mount |
Temperature: -40 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
Package: 3414 VIA |
View Details | ||
| Part Number: | Input (V): 28.0 (16.0 - 50.0) |
Output (V): 24.0 (14.4 - 26.4) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Board Mount Long Pin |
Temperature: -40 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
Package: 3414 VIA |
View Details | ||
| Part Number: | Input (V): 28.0 (16.0 - 50.0) |
Output (V): 24.0 (14.4 - 26.4) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Board Mount Short Pin |
Temperature: -20 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
Package: 3414 VIA |
View Details | ||
| Part Number: | Input (V): 28.0 (16.0 - 50.0) |
Output (V): 24.0 (14.4 - 26.4) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Board Mount Long Pin |
Temperature: -20 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
Package: 3414 VIA |
View Details | ||
| Part Number: | Input (V): 28.0 (16.0 - 50.0) |
Output (V): 24.0 (14.4 - 26.4) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 28.0 (16.0 - 50.0) |
Output (V): 24.0 (14.4 - 26.4) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 28.0 (16.0 - 50.0) |
Output (V): 24.0 (14.4 - 26.4) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 28.0 (16.0 - 50.0) |
Output (V): 24.0 (14.4 - 26.4) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 28.0 (16.0 - 50.0) |
Output (V): 28.0 (16.8 - 30.8) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Board Mount Short Pin |
Temperature: -40 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
Package: 3414 VIA |
View Details | ||
| Part Number: | Input (V): 28.0 (16.0 - 50.0) |
Output (V): 28.0 (16.8 - 30.8) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Board Mount Long Pin |
Temperature: -20 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
Package: 3414 VIA |
View Details | ||
| Part Number: | Input (V): 28.0 (16.0 - 50.0) |
Output (V): 28.0 (16.8 - 30.8) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Board Mount Short Pin |
Temperature: -20 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
Package: 3414 VIA |
View Details | ||
| Part Number: | Input (V): 28.0 (16.0 - 50.0) |
Output (V): 28.0 (16.8 - 30.8) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Chassis Mount |
Temperature: -40 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
Package: 3414 VIA |
View Details | ||
| Part Number: | Input (V): 28.0 (16.0 - 50.0) |
Output (V): 28.0 (16.8 - 30.8) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Chassis Mount |
Temperature: -55 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
Package: 3414 VIA |
View Details | ||
| Part Number: | Input (V): 28.0 (16.0 - 50.0) |
Output (V): 28.0 (16.8 - 30.8) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Board Mount Long Pin |
Temperature: -55 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
Package: 3414 VIA |
View Details | ||
| Part Number: | Input (V): 28.0 (16.0 - 50.0) |
Output (V): 28.0 (16.8 - 30.8) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Board Mount Short Pin |
Temperature: -55 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
Package: 3414 VIA |
View Details | ||
| Part Number: | Input (V): 28.0 (16.0 - 50.0) |
Output (V): 28.0 (16.8 - 30.8) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Board Mount Long Pin |
Temperature: -40 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
Package: 3414 VIA |
View Details | ||
| Part Number: | Input (V): 28.0 (16.0 - 50.0) |
Output (V): 28.0 (16.8 - 30.8) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Chassis Mount |
Temperature: -20 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
Package: 3414 VIA |
View Details | ||
| Part Number: | Input (V): 28.0 (16.0 - 50.0) |
Output (V): 28.0 (22.0 - 30.8) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 28.0 (16.0 - 50.0) |
Output (V): 28.0 (22.0 - 30.8) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 28.0 (16.0 - 50.0) |
Output (V): 28.0 (22.0 - 30.8) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 28.0 (16.0 - 50.0) |
Output (V): 28.0 (22.0 - 30.8) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 28.0 (16.0 - 50.0) |
Output (V): 48.0 (28.8 - 52.8) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Chassis Mount |
Temperature: -40 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
Package: 3414 VIA |
View Details | ||
| Part Number: | Input (V): 28.0 (16.0 - 50.0) |
Output (V): 48.0 (28.8 - 52.8) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Chassis Mount |
Temperature: -55 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
Package: 3414 VIA |
View Details | ||
| Part Number: | Input (V): 28.0 (16.0 - 50.0) |
Output (V): 48.0 (28.8 - 52.8) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Board Mount Long Pin |
Temperature: -55 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
Package: 3414 VIA |
View Details | ||
| Part Number: | Input (V): 28.0 (16.0 - 50.0) |
Output (V): 48.0 (28.8 - 52.8) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Board Mount Short Pin |
Temperature: -40 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
Package: 3414 VIA |
View Details | ||
| Part Number: | Input (V): 28.0 (16.0 - 50.0) |
Output (V): 48.0 (28.8 - 52.8) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Board Mount Short Pin |
Temperature: -20 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
Package: 3414 VIA |
View Details | ||
| Part Number: | Input (V): 28.0 (16.0 - 50.0) |
Output (V): 48.0 (28.8 - 52.8) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Chassis Mount |
Temperature: -20 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
Package: 3414 VIA |
View Details | ||
| Part Number: | Input (V): 28.0 (16.0 - 50.0) |
Output (V): 48.0 (28.8 - 52.8) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Board Mount Short Pin |
Temperature: -55 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
Package: 3414 VIA |
View Details | ||
| Part Number: | Input (V): 28.0 (16.0 - 50.0) |
Output (V): 48.0 (28.8 - 52.8) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Board Mount Long Pin |
Temperature: -40 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
Package: 3414 VIA |
View Details | ||
| Part Number: | Input (V): 28.0 (16.0 - 50.0) |
Output (V): 48.0 (28.8 - 52.8) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 28.0 (16.0 - 50.0) |
Output (V): 48.0 (28.8 - 52.8) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 28.0 (16.0 - 50.0) |
Output (V): 48.0 (28.8 - 52.8) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 28.0 (16.0 - 50.0) |
Output (V): 48.0 (28.8 - 52.8) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 30.0 (9.0 - 50.0) |
Output (V): 3.3 (2.97 - 3.63) |
Power (W): 80.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 30.0 (9.0 - 50.0) |
Output (V): 3.3 (2.97 - 3.63) |
Power (W): 80.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 30.0 (9.0 - 50.0) |
Output (V): 3.3 (2.97 - 3.63) |
Power (W): 80.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 30.0 (9.0 - 50.0) |
Output (V): 3.3 (2.97 - 3.63) |
Power (W): 80.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 30.0 (9.0 - 50.0) |
Output (V): 5.0 (3.5 - 5.5) |
Power (W): 80.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 30.0 (9.0 - 50.0) |
Output (V): 5.0 (3.5 - 5.5) |
Power (W): 80.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 30.0 (9.0 - 50.0) |
Output (V): 5.0 (3.5 - 5.5) |
Power (W): 80.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 30.0 (9.0 - 50.0) |
Output (V): 5.0 (3.5 - 5.5) |
Power (W): 80.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 30.0 (9.0 - 50.0) |
Output (V): 12.0 (7.2 - 13.2) |
Power (W): 60.0 |
Control Interface: Analog |
Optimized for: Array/Standalone |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 24.84 x 22.80 x 7.21mm |
Dimensions in.: 0.978 x 0.898 x 0.284in |
Package: 2322 ChiP |
View Details | ||
| Part Number: | Input (V): 30.0 (9.0 - 50.0) |
Output (V): 12.0 (7.2 - 13.2) |
Power (W): 60.0 |
Control Interface: Analog |
Optimized for: Array/Standalone |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 24.84 x 22.80 x 7.21mm |
Dimensions in.: 0.978 x 0.898 x 0.284in |
Package: 2322 ChiP |
View Details | ||
| Part Number: | Input (V): 30.0 (9.0 - 50.0) |
Output (V): 12.0 (7.2 - 13.2) |
Power (W): 160.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 30.0 (9.0 - 50.0) |
Output (V): 12.0 (7.2 - 13.2) |
Power (W): 160.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 30.0 (9.0 - 50.0) |
Output (V): 12.0 (7.2 - 13.2) |
Power (W): 160.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 30.0 (9.0 - 50.0) |
Output (V): 12.0 (7.2 - 13.2) |
Power (W): 160.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 30.0 (9.0 - 50.0) |
Output (V): 15.0 (9.0 - 16.5) |
Power (W): 60.0 |
Control Interface: Analog |
Optimized for: Array/Standalone |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 24.84 x 22.80 x 7.21mm |
Dimensions in.: 0.978 x 0.898 x 0.284in |
Package: 2322 ChiP |
View Details | ||
| Part Number: | Input (V): 30.0 (9.0 - 50.0) |
Output (V): 15.0 (9.0 - 16.5) |
Power (W): 60.0 |
Control Interface: Analog |
Optimized for: Array/Standalone |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 24.84 x 22.80 x 7.21mm |
Dimensions in.: 0.978 x 0.898 x 0.284in |
Package: 2322 ChiP |
View Details | ||
| Part Number: | Input (V): 30.0 (9.0 - 50.0) |
Output (V): 15.0 (9.0 - 16.5) |
Power (W): 160.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 30.0 (9.0 - 50.0) |
Output (V): 15.0 (9.0 - 16.5) |
Power (W): 160.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 30.0 (9.0 - 50.0) |
Output (V): 15.0 (9.0 - 16.5) |
Power (W): 160.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 30.0 (9.0 - 50.0) |
Output (V): 15.0 (9.0 - 16.5) |
Power (W): 160.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 30.0 (9.0 - 50.0) |
Output (V): 24.0 (14.4 - 26.4) |
Power (W): 60.0 |
Control Interface: Analog |
Optimized for: Array/Standalone |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 24.84 x 22.80 x 7.21mm |
Dimensions in.: 0.978 x 0.898 x 0.284in |
Package: 2322 ChiP |
View Details | ||
| Part Number: | Input (V): 30.0 (9.0 - 50.0) |
Output (V): 24.0 (14.4 - 26.4) |
Power (W): 60.0 |
Control Interface: Analog |
Optimized for: Array/Standalone |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 24.84 x 22.80 x 7.21mm |
Dimensions in.: 0.978 x 0.898 x 0.284in |
Package: 2322 ChiP |
View Details | ||
| Part Number: | Input (V): 30.0 (9.0 - 50.0) |
Output (V): 24.0 (14.4 - 26.4) |
Power (W): 160.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 30.0 (9.0 - 50.0) |
Output (V): 24.0 (14.4 - 26.4) |
Power (W): 160.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 30.0 (9.0 - 50.0) |
Output (V): 28.0 (16.8 - 30.8) |
Power (W): 60.0 |
Control Interface: Analog |
Optimized for: Array/Standalone |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 24.84 x 22.80 x 7.21mm |
Dimensions in.: 0.978 x 0.898 x 0.284in |
Package: 2322 ChiP |
View Details | ||
| Part Number: | Input (V): 30.0 (9.0 - 50.0) |
Output (V): 28.0 (16.8 - 30.8) |
Power (W): 60.0 |
Control Interface: Analog |
Optimized for: Array/Standalone |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 24.84 x 22.80 x 7.21mm |
Dimensions in.: 0.978 x 0.898 x 0.284in |
Package: 2322 ChiP |
View Details | ||
| Part Number: | Input (V): 30.0 (9.0 - 50.0) |
Output (V): 28.0 (16.8 - 30.8) |
Power (W): 160.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 30.0 (9.0 - 50.0) |
Output (V): 28.0 (16.8 - 30.8) |
Power (W): 160.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 30.0 (9.0 - 50.0) |
Output (V): 28.0 (16.8 - 30.8) |
Power (W): 160.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 30.0 (9.0 - 50.0) |
Output (V): 28.0 (16.8 - 30.8) |
Power (W): 160.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 30.0 (9.0 - 50.0) |
Output (V): 48.0 (28.8 - 52.8) |
Power (W): 60.0 |
Control Interface: Analog |
Optimized for: Array/Standalone |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 24.84 x 22.80 x 7.21mm |
Dimensions in.: 0.978 x 0.898 x 0.284in |
Package: 2322 ChiP |
View Details | ||
| Part Number: | Input (V): 30.0 (9.0 - 50.0) |
Output (V): 48.0 (28.8 - 52.8) |
Power (W): 60.0 |
Control Interface: Analog |
Optimized for: Array/Standalone |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 24.84 x 22.80 x 7.21mm |
Dimensions in.: 0.978 x 0.898 x 0.284in |
Package: 2322 ChiP |
View Details | ||
| Part Number: | Input (V): 30.0 (9.0 - 50.0) |
Output (V): 48.0 (28.8 - 52.8) |
Power (W): 160.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 30.0 (9.0 - 50.0) |
Output (V): 48.0 (28.8 - 52.8) |
Power (W): 160.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 42.0 (9.0 - 75.0) |
Output (V): 12.0 (9.0 - 13.2) |
Power (W): 80.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 42.0 (9.0 - 75.0) |
Output (V): 12.0 (9.0 - 13.2) |
Power (W): 80.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 42.0 (9.0 - 75.0) |
Output (V): 15.0 (11.25 - 16.5) |
Power (W): 80.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 42.0 (9.0 - 75.0) |
Output (V): 15.0 (11.25 - 16.5) |
Power (W): 80.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 42.0 (9.0 - 75.0) |
Output (V): 15.0 (11.25 - 16.5) |
Power (W): 80.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 42.0 (9.0 - 75.0) |
Output (V): 15.0 (11.25 - 16.5) |
Power (W): 80.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 42.0 (9.0 - 75.0) |
Output (V): 24.0 (18.0 - 26.4) |
Power (W): 80.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 42.0 (9.0 - 75.0) |
Output (V): 24.0 (18.0 - 26.4) |
Power (W): 80.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 42.0 (9.0 - 75.0) |
Output (V): 28.0 (21.0 - 30.8) |
Power (W): 80.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 42.0 (9.0 - 75.0) |
Output (V): 28.0 (21.0 - 30.8) |
Power (W): 80.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 42.0 (9.0 - 75.0) |
Output (V): 48.0 (36.0 - 52.8) |
Power (W): 80.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 42.0 (9.0 - 75.0) |
Output (V): 48.0 (36.0 - 52.8) |
Power (W): 80.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 43.0 (14.0 - 72.0) |
Output (V): 3.3 (2.97 - 3.63) |
Power (W): 35.0 |
Control Interface: Analog |
Optimized for: Array/Standalone |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 24.84 x 22.80 x 7.21mm |
Dimensions in.: 0.978 x 0.898 x 0.284in |
Package: 2322 ChiP |
View Details | ||
| Part Number: | Input (V): 43.0 (14.0 - 72.0) |
Output (V): 3.3 (2.97 - 3.63) |
Power (W): 35.0 |
Control Interface: Analog |
Optimized for: Array/Standalone |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 24.84 x 22.80 x 7.21mm |
Dimensions in.: 0.978 x 0.898 x 0.284in |
Package: 2322 ChiP |
View Details | ||
| Part Number: | Input (V): 43.0 (14.0 - 72.0) |
Output (V): 5.0 (3.5 - 5.5) |
Power (W): 50.0 |
Control Interface: Analog |
Optimized for: Array/Standalone |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 24.84 x 22.80 x 7.21mm |
Dimensions in.: 0.978 x 0.898 x 0.284in |
Package: 2322 ChiP |
View Details | ||
| Part Number: | Input (V): 43.0 (14.0 - 72.0) |
Output (V): 5.0 (3.5 - 5.5) |
Power (W): 50.0 |
Control Interface: Analog |
Optimized for: Array/Standalone |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 24.84 x 22.80 x 7.21mm |
Dimensions in.: 0.978 x 0.898 x 0.284in |
Package: 2322 ChiP |
View Details | ||
| Part Number: | Input (V): 43.0 (14.0 - 72.0) |
Output (V): 12.0 (7.2 - 13.2) |
Power (W): 100.0 |
Control Interface: Analog |
Optimized for: Array/Standalone |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 24.84 x 22.80 x 7.21mm |
Dimensions in.: 0.978 x 0.898 x 0.284in |
Package: 2322 ChiP |
View Details | ||
| Part Number: | Input (V): 43.0 (14.0 - 72.0) |
Output (V): 12.0 (7.2 - 13.2) |
Power (W): 100.0 |
Control Interface: Analog |
Optimized for: Array/Standalone |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 24.84 x 22.80 x 7.21mm |
Dimensions in.: 0.978 x 0.898 x 0.284in |
Package: 2322 ChiP |
View Details | ||
| Part Number: | Input (V): 43.0 (14.0 - 72.0) |
Output (V): 15.0 (9.0 - 16.5) |
Power (W): 100.0 |
Control Interface: Analog |
Optimized for: Array/Standalone |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 24.84 x 22.80 x 7.21mm |
Dimensions in.: 0.978 x 0.898 x 0.284in |
Package: 2322 ChiP |
View Details | ||
| Part Number: | Input (V): 43.0 (14.0 - 72.0) |
Output (V): 15.0 (9.0 - 16.5) |
Power (W): 100.0 |
Control Interface: Analog |
Optimized for: Array/Standalone |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 24.84 x 22.80 x 7.21mm |
Dimensions in.: 0.978 x 0.898 x 0.284in |
Package: 2322 ChiP |
View Details | ||
| Part Number: | Input (V): 43.0 (14.0 - 72.0) |
Output (V): 24.0 (14.4 - 26.4) |
Power (W): 100.0 |
Control Interface: Analog |
Optimized for: Array/Standalone |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 24.84 x 22.80 x 7.21mm |
Dimensions in.: 0.978 x 0.898 x 0.284in |
Package: 2322 ChiP |
View Details | ||
| Part Number: | Input (V): 43.0 (14.0 - 72.0) |
Output (V): 24.0 (14.4 - 26.4) |
Power (W): 100.0 |
Control Interface: Analog |
Optimized for: Array/Standalone |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 24.84 x 22.80 x 7.21mm |
Dimensions in.: 0.978 x 0.898 x 0.284in |
Package: 2322 ChiP |
View Details | ||
| Part Number: | Input (V): 43.0 (14.0 - 72.0) |
Output (V): 28.0 (16.8 - 30.8) |
Power (W): 100.0 |
Control Interface: Analog |
Optimized for: Array/Standalone |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 24.84 x 22.80 x 7.21mm |
Dimensions in.: 0.978 x 0.898 x 0.284in |
Package: 2322 ChiP |
View Details | ||
| Part Number: | Input (V): 43.0 (14.0 - 72.0) |
Output (V): 28.0 (16.8 - 30.8) |
Power (W): 100.0 |
Control Interface: Analog |
Optimized for: Array/Standalone |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 24.84 x 22.80 x 7.21mm |
Dimensions in.: 0.978 x 0.898 x 0.284in |
Package: 2322 ChiP |
View Details | ||
| Part Number: | Input (V): 43.0 (14.0 - 72.0) |
Output (V): 48.0 (28.8 - 52.8) |
Power (W): 100.0 |
Control Interface: Analog |
Optimized for: Array/Standalone |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 24.84 x 22.80 x 7.21mm |
Dimensions in.: 0.978 x 0.898 x 0.284in |
Package: 2322 ChiP |
View Details | ||
| Part Number: | Input (V): 43.0 (14.0 - 72.0) |
Output (V): 48.0 (28.8 - 52.8) |
Power (W): 100.0 |
Control Interface: Analog |
Optimized for: Array/Standalone |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 24.84 x 22.80 x 7.21mm |
Dimensions in.: 0.978 x 0.898 x 0.284in |
Package: 2322 ChiP |
View Details | ||
| Part Number: | Input (V): 48.0 (36.0 - 75.0) |
Output (V): 5.0 (4.0 - 5.5) |
Power (W): 160.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Chassis Mount |
Temperature: -40 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
Package: 3414 VIA |
View Details | ||
| Part Number: | Input (V): 48.0 (36.0 - 75.0) |
Output (V): 5.0 (4.0 - 5.5) |
Power (W): 160.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Board Mount Long Pin |
Temperature: -20 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
Package: 3414 VIA |
View Details | ||
| Part Number: | Input (V): 48.0 (36.0 - 75.0) |
Output (V): 5.0 (4.0 - 5.5) |
Power (W): 160.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Board Mount Short Pin |
Temperature: -40 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
Package: 3414 VIA |
View Details | ||
| Part Number: | Input (V): 48.0 (36.0 - 75.0) |
Output (V): 5.0 (4.0 - 5.5) |
Power (W): 160.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Chassis Mount |
Temperature: -20 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
Package: 3414 VIA |
View Details | ||
| Part Number: | Input (V): 48.0 (36.0 - 75.0) |
Output (V): 5.0 (4.0 - 5.5) |
Power (W): 160.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Board Mount Long Pin |
Temperature: -40 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
Package: 3414 VIA |
View Details | ||
| Part Number: | Input (V): 48.0 (36.0 - 75.0) |
Output (V): 5.0 (4.0 - 5.5) |
Power (W): 160.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Board Mount Short Pin |
Temperature: -20 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
Package: 3414 VIA |
View Details | ||
| Part Number: | Input (V): 48.0 (36.0 - 75.0) |
Output (V): 5.0 (4.0 - 5.5) |
Power (W): 160.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 48.0 (36.0 - 75.0) |
Output (V): 5.0 (4.0 - 5.5) |
Power (W): 160.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 48.0 (36.0 - 75.0) |
Output (V): 12.0 (7.2 - 13.2) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Board Mount Short Pin |
Temperature: -20 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
Package: 3414 VIA |
View Details | ||
| Part Number: | Input (V): 48.0 (36.0 - 75.0) |
Output (V): 12.0 (7.2 - 13.2) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Board Mount Long Pin |
Temperature: -20 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
Package: 3414 VIA |
View Details | ||
| Part Number: | Input (V): 48.0 (36.0 - 75.0) |
Output (V): 12.0 (7.2 - 13.2) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Chassis Mount |
Temperature: -40 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
Package: 3414 VIA |
View Details | ||
| Part Number: | Input (V): 48.0 (36.0 - 75.0) |
Output (V): 12.0 (7.2 - 13.2) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Board Mount Long Pin |
Temperature: -40 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
Package: 3414 VIA |
View Details | ||
| Part Number: | Input (V): 48.0 (36.0 - 75.0) |
Output (V): 12.0 (7.2 - 13.2) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Chassis Mount |
Temperature: -20 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
Package: 3414 VIA |
View Details | ||
| Part Number: | Input (V): 48.0 (36.0 - 75.0) |
Output (V): 12.0 (7.2 - 13.2) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Board Mount Short Pin |
Temperature: -40 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
Package: 3414 VIA |
View Details | ||
| Part Number: | Input (V): 48.0 (36.0 - 75.0) |
Output (V): 12.0 (7.2 - 13.2) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 48.0 (36.0 - 75.0) |
Output (V): 12.0 (7.2 - 13.2) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 48.0 (36.0 - 75.0) |
Output (V): 15.0 (9.0 - 16.5) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Board Mount Short Pin |
Temperature: -20 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
Package: 3414 VIA |
View Details | ||
| Part Number: | Input (V): 48.0 (36.0 - 75.0) |
Output (V): 15.0 (9.0 - 16.5) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Board Mount Long Pin |
Temperature: -40 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
Package: 3414 VIA |
View Details | ||
| Part Number: | Input (V): 48.0 (36.0 - 75.0) |
Output (V): 15.0 (9.0 - 16.5) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Chassis Mount |
Temperature: -40 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
Package: 3414 VIA |
View Details | ||
| Part Number: | Input (V): 48.0 (36.0 - 75.0) |
Output (V): 15.0 (9.0 - 16.5) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Chassis Mount |
Temperature: -20 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
Package: 3414 VIA |
View Details | ||
| Part Number: | Input (V): 48.0 (36.0 - 75.0) |
Output (V): 15.0 (9.0 - 16.5) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Board Mount Short Pin |
Temperature: -40 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
Package: 3414 VIA |
View Details | ||
| Part Number: | Input (V): 48.0 (36.0 - 75.0) |
Output (V): 15.0 (9.0 - 16.5) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Board Mount Long Pin |
Temperature: -20 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
Package: 3414 VIA |
View Details | ||
| Part Number: | Input (V): 48.0 (36.0 - 75.0) |
Output (V): 15.0 (9.0 - 16.5) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 48.0 (36.0 - 75.0) |
Output (V): 15.0 (9.0 - 16.5) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 48.0 (36.0 - 75.0) |
Output (V): 24.0 (14.4 - 26.4) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Board Mount Short Pin |
Temperature: -20 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
Package: 3414 VIA |
View Details | ||
| Part Number: | Input (V): 48.0 (36.0 - 75.0) |
Output (V): 24.0 (14.4 - 26.4) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Chassis Mount |
Temperature: -20 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
Package: 3414 VIA |
View Details | ||
| Part Number: | Input (V): 48.0 (36.0 - 75.0) |
Output (V): 24.0 (14.4 - 26.4) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Board Mount Long Pin |
Temperature: -40 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
Package: 3414 VIA |
View Details | ||
| Part Number: | Input (V): 48.0 (36.0 - 75.0) |
Output (V): 24.0 (14.4 - 26.4) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Chassis Mount |
Temperature: -40 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
Package: 3414 VIA |
View Details | ||
| Part Number: | Input (V): 48.0 (36.0 - 75.0) |
Output (V): 24.0 (14.4 - 26.4) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Board Mount Long Pin |
Temperature: -20 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
Package: 3414 VIA |
View Details | ||
| Part Number: | Input (V): 48.0 (36.0 - 75.0) |
Output (V): 24.0 (14.4 - 26.4) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Board Mount Short Pin |
Temperature: -40 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
Package: 3414 VIA |
View Details | ||
| Part Number: | Input (V): 48.0 (36.0 - 75.0) |
Output (V): 24.0 (14.4 - 26.4) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 48.0 (36.0 - 75.0) |
Output (V): 24.0 (14.4 - 26.4) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 48.0 (36.0 - 75.0) |
Output (V): 28.0 (16.8 - 30.8) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Chassis Mount |
Temperature: -40 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
Package: 3414 VIA |
View Details | ||
| Part Number: | Input (V): 48.0 (36.0 - 75.0) |
Output (V): 28.0 (16.8 - 30.8) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Board Mount Long Pin |
Temperature: -40 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
Package: 3414 VIA |
View Details | ||
| Part Number: | Input (V): 48.0 (36.0 - 75.0) |
Output (V): 28.0 (16.8 - 30.8) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Board Mount Short Pin |
Temperature: -40 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
Package: 3414 VIA |
View Details | ||
| Part Number: | Input (V): 48.0 (36.0 - 75.0) |
Output (V): 28.0 (16.8 - 30.8) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Chassis Mount |
Temperature: -20 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
Package: 3414 VIA |
View Details | ||
| Part Number: | Input (V): 48.0 (36.0 - 75.0) |
Output (V): 28.0 (16.8 - 30.8) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Board Mount Short Pin |
Temperature: -20 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
Package: 3414 VIA |
View Details | ||
| Part Number: | Input (V): 48.0 (36.0 - 75.0) |
Output (V): 28.0 (16.8 - 30.8) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Board Mount Long Pin |
Temperature: -20 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
Package: 3414 VIA |
View Details | ||
| Part Number: | Input (V): 48.0 (36.0 - 75.0) |
Output (V): 28.0 (16.8 - 30.8) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 48.0 (36.0 - 75.0) |
Output (V): 28.0 (16.8 - 30.8) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 48.0 (36.0 - 75.0) |
Output (V): 28.0 (16.8 - 30.8) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 48.0 (36.0 - 75.0) |
Output (V): 28.0 (16.8 - 30.8) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 48.0 (36.0 - 75.0) |
Output (V): 36.0 (21.6 - 39.6) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 48.0 (36.0 - 75.0) |
Output (V): 36.0 (21.6 - 39.6) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 48.0 (36.0 - 75.0) |
Output (V): 36.0 (21.6 - 39.6) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 48.0 (36.0 - 75.0) |
Output (V): 36.0 (21.6 - 39.6) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 48.0 (36.0 - 75.0) |
Output (V): 48.0 (28.8 - 52.8) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Chassis Mount |
Temperature: -40 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
Package: 3414 VIA |
View Details | ||
| Part Number: | Input (V): 48.0 (36.0 - 75.0) |
Output (V): 48.0 (28.8 - 52.8) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Board Mount Long Pin |
Temperature: -40 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
Package: 3414 VIA |
View Details | ||
| Part Number: | Input (V): 48.0 (36.0 - 75.0) |
Output (V): 48.0 (28.8 - 52.8) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Board Mount Long Pin |
Temperature: -20 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
Package: 3414 VIA |
View Details | ||
| Part Number: | Input (V): 48.0 (36.0 - 75.0) |
Output (V): 48.0 (28.8 - 52.8) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Board Mount Short Pin |
Temperature: -40 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
Package: 3414 VIA |
View Details | ||
| Part Number: | Input (V): 48.0 (36.0 - 75.0) |
Output (V): 48.0 (28.8 - 52.8) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Board Mount Short Pin |
Temperature: -20 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
Package: 3414 VIA |
View Details | ||
| Part Number: | Input (V): 48.0 (36.0 - 75.0) |
Output (V): 48.0 (28.8 - 52.8) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Chassis Mount |
Temperature: -20 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
Package: 3414 VIA |
View Details | ||
| Part Number: | Input (V): 48.0 (36.0 - 75.0) |
Output (V): 48.0 (28.8 - 52.8) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 48.0 (36.0 - 75.0) |
Output (V): 48.0 (28.8 - 52.8) |
Power (W): 320.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 100.0 (43.0 - 154.0) |
Output (V): 3.3 (2.97 - 3.63) |
Power (W): 40.0 |
Control Interface: Analog |
Optimized for: Array/Standalone |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 24.84 x 22.80 x 7.21mm |
Dimensions in.: 0.978 x 0.898 x 0.284in |
Package: 2322 ChiP |
View Details | ||
| Part Number: | Input (V): 100.0 (43.0 - 154.0) |
Output (V): 3.3 (2.97 - 3.63) |
Power (W): 40.0 |
Control Interface: Analog |
Optimized for: Array/Standalone |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 24.84 x 22.80 x 7.21mm |
Dimensions in.: 0.978 x 0.898 x 0.284in |
Package: 2322 ChiP |
View Details | ||
| Part Number: | Input (V): 100.0 (43.0 - 154.0) |
Output (V): 3.3 (2.97 - 3.63) |
Power (W): 80.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 100.0 (43.0 - 154.0) |
Output (V): 3.3 (2.97 - 3.63) |
Power (W): 80.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 100.0 (43.0 - 154.0) |
Output (V): 3.3 (2.97 - 3.63) |
Power (W): 80.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 100.0 (43.0 - 154.0) |
Output (V): 3.3 (2.97 - 3.63) |
Power (W): 80.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 100.0 (43.0 - 154.0) |
Output (V): 5.0 (3.5 - 5.5) |
Power (W): 60.0 |
Control Interface: Analog |
Optimized for: Array/Standalone |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 24.84 x 22.80 x 7.21mm |
Dimensions in.: 0.978 x 0.898 x 0.284in |
Package: 2322 ChiP |
View Details | ||
| Part Number: | Input (V): 100.0 (43.0 - 154.0) |
Output (V): 5.0 (3.5 - 5.5) |
Power (W): 60.0 |
Control Interface: Analog |
Optimized for: Array/Standalone |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 24.84 x 22.80 x 7.21mm |
Dimensions in.: 0.978 x 0.898 x 0.284in |
Package: 2322 ChiP |
View Details | ||
| Part Number: | Input (V): 100.0 (43.0 - 154.0) |
Output (V): 5.0 (3.5 - 5.5) |
Power (W): 120.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 100.0 (43.0 - 154.0) |
Output (V): 5.0 (3.5 - 5.5) |
Power (W): 120.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 100.0 (43.0 - 154.0) |
Output (V): 5.0 (3.5 - 5.5) |
Power (W): 120.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 100.0 (43.0 - 154.0) |
Output (V): 5.0 (3.5 - 5.5) |
Power (W): 120.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 100.0 (43.0 - 154.0) |
Output (V): 12.0 (7.2 - 13.2) |
Power (W): 120.0 |
Control Interface: Analog |
Optimized for: Array/Standalone |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 24.84 x 22.80 x 7.21mm |
Dimensions in.: 0.978 x 0.898 x 0.284in |
Package: 2322 ChiP |
View Details | ||
| Part Number: | Input (V): 100.0 (43.0 - 154.0) |
Output (V): 12.0 (7.2 - 13.2) |
Power (W): 120.0 |
Control Interface: Analog |
Optimized for: Array/Standalone |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 24.84 x 22.80 x 7.21mm |
Dimensions in.: 0.978 x 0.898 x 0.284in |
Package: 2322 ChiP |
View Details | ||
| Part Number: | Input (V): 100.0 (43.0 - 154.0) |
Output (V): 12.0 (7.2 - 13.2) |
Power (W): 240.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 100.0 (43.0 - 154.0) |
Output (V): 12.0 (7.2 - 13.2) |
Power (W): 240.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 100.0 (43.0 - 154.0) |
Output (V): 12.0 (7.2 - 13.2) |
Power (W): 240.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 100.0 (43.0 - 154.0) |
Output (V): 12.0 (7.2 - 13.2) |
Power (W): 240.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 100.0 (43.0 - 154.0) |
Output (V): 15.0 (9.0 - 16.5) |
Power (W): 120.0 |
Control Interface: Analog |
Optimized for: Array/Standalone |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 24.84 x 22.80 x 7.21mm |
Dimensions in.: 0.978 x 0.898 x 0.284in |
Package: 2322 ChiP |
View Details | ||
| Part Number: | Input (V): 100.0 (43.0 - 154.0) |
Output (V): 15.0 (9.0 - 16.5) |
Power (W): 120.0 |
Control Interface: Analog |
Optimized for: Array/Standalone |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 24.84 x 22.80 x 7.21mm |
Dimensions in.: 0.978 x 0.898 x 0.284in |
Package: 2322 ChiP |
View Details | ||
| Part Number: | Input (V): 100.0 (43.0 - 154.0) |
Output (V): 15.0 (9.0 - 16.5) |
Power (W): 240.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 100.0 (43.0 - 154.0) |
Output (V): 15.0 (9.0 - 16.5) |
Power (W): 240.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 100.0 (43.0 - 154.0) |
Output (V): 15.0 (9.0 - 16.5) |
Power (W): 240.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 100.0 (43.0 - 154.0) |
Output (V): 15.0 (9.0 - 16.5) |
Power (W): 240.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 100.0 (43.0 - 154.0) |
Output (V): 24.0 (14.4 - 26.4) |
Power (W): 120.0 |
Control Interface: Analog |
Optimized for: Array/Standalone |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 24.84 x 22.80 x 7.21mm |
Dimensions in.: 0.978 x 0.898 x 0.284in |
Package: 2322 ChiP |
View Details | ||
| Part Number: | Input (V): 100.0 (43.0 - 154.0) |
Output (V): 24.0 (14.4 - 26.4) |
Power (W): 120.0 |
Control Interface: Analog |
Optimized for: Array/Standalone |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 24.84 x 22.80 x 7.21mm |
Dimensions in.: 0.978 x 0.898 x 0.284in |
Package: 2322 ChiP |
View Details | ||
| Part Number: | Input (V): 100.0 (43.0 - 154.0) |
Output (V): 24.0 (14.4 - 26.4) |
Power (W): 240.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 100.0 (43.0 - 154.0) |
Output (V): 24.0 (14.4 - 26.4) |
Power (W): 240.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 100.0 (43.0 - 154.0) |
Output (V): 24.0 (14.4 - 26.4) |
Power (W): 240.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 100.0 (43.0 - 154.0) |
Output (V): 24.0 (14.4 - 26.4) |
Power (W): 240.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 100.0 (43.0 - 154.0) |
Output (V): 28.0 (16.8 - 30.8) |
Power (W): 120.0 |
Control Interface: Analog |
Optimized for: Array/Standalone |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 24.84 x 22.80 x 7.21mm |
Dimensions in.: 0.978 x 0.898 x 0.284in |
Package: 2322 ChiP |
View Details | ||
| Part Number: | Input (V): 100.0 (43.0 - 154.0) |
Output (V): 28.0 (16.8 - 30.8) |
Power (W): 120.0 |
Control Interface: Analog |
Optimized for: Array/Standalone |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 24.84 x 22.80 x 7.21mm |
Dimensions in.: 0.978 x 0.898 x 0.284in |
Package: 2322 ChiP |
View Details | ||
| Part Number: | Input (V): 100.0 (43.0 - 154.0) |
Output (V): 28.0 (16.8 - 30.8) |
Power (W): 240.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 100.0 (43.0 - 154.0) |
Output (V): 28.0 (16.8 - 30.8) |
Power (W): 240.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 100.0 (43.0 - 154.0) |
Output (V): 28.0 (16.8 - 30.8) |
Power (W): 240.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 100.0 (43.0 - 154.0) |
Output (V): 28.0 (16.8 - 30.8) |
Power (W): 240.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 100.0 (43.0 - 154.0) |
Output (V): 48.0 (28.8 - 52.8) |
Power (W): 120.0 |
Control Interface: Analog |
Optimized for: Array/Standalone |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 24.84 x 22.80 x 7.21mm |
Dimensions in.: 0.978 x 0.898 x 0.284in |
Package: 2322 ChiP |
View Details | ||
| Part Number: | Input (V): 100.0 (43.0 - 154.0) |
Output (V): 48.0 (28.8 - 52.8) |
Power (W): 120.0 |
Control Interface: Analog |
Optimized for: Array/Standalone |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 24.84 x 22.80 x 7.21mm |
Dimensions in.: 0.978 x 0.898 x 0.284in |
Package: 2322 ChiP |
View Details | ||
| Part Number: | Input (V): 100.0 (43.0 - 154.0) |
Output (V): 48.0 (28.8 - 52.8) |
Power (W): 240.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 100.0 (43.0 - 154.0) |
Output (V): 48.0 (28.8 - 52.8) |
Power (W): 240.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 100.0 (43.0 - 154.0) |
Output (V): 48.0 (28.8 - 52.8) |
Power (W): 240.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 100.0 (43.0 - 154.0) |
Output (V): 48.0 (28.8 - 52.8) |
Power (W): 240.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 110.0 (60.0 - 154.0) |
Output (V): 13.8 (8.28 - 15.18) |
Power (W): 300.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 110.0 (60.0 - 154.0) |
Output (V): 13.8 (8.28 - 15.18) |
Power (W): 300.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 110.0 (60.0 - 154.0) |
Output (V): 13.8 (8.28 - 15.18) |
Power (W): 300.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 110.0 (60.0 - 154.0) |
Output (V): 13.8 (8.28 - 15.18) |
Power (W): 300.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
Package: 3623 ChiP |
View Details | ||
| Part Number: | Input (V): 270.0 (160.0 - 420.0) |
Output (V): 3.3 (2.97 - 3.63) |
Power (W): 150.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
Package: 4623 ChiP |
View Details | ||
| Part Number: | Input (V): 270.0 (160.0 - 420.0) |
Output (V): 3.3 (2.97 - 3.63) |
Power (W): 150.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
Package: 4623 ChiP |
View Details | ||
| Part Number: | Input (V): 270.0 (160.0 - 420.0) |
Output (V): 3.3 (2.97 - 3.63) |
Power (W): 150.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
Package: 4623 ChiP |
View Details | ||
| Part Number: | Input (V): 270.0 (160.0 - 420.0) |
Output (V): 3.3 (2.97 - 3.63) |
Power (W): 150.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
Package: 4623 ChiP |
View Details | ||
| Part Number: | Input (V): 270.0 (160.0 - 420.0) |
Output (V): 5.0 (4.0 - 5.5) |
Power (W): 250.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Chassis Mount |
Temperature: -40 to 125°C |
Dimensions mm: 95.10 x 35.50 x 9.40mm |
Dimensions in.: 3.750 x 1.400 x 0.370in |
Package: 3714 VIA |
View Details | ||
| Part Number: | Input (V): 270.0 (160.0 - 420.0) |
Output (V): 5.0 (4.0 - 5.5) |
Power (W): 250.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Board Mount Short Pin |
Temperature: -20 to 125°C |
Dimensions mm: 95.10 x 35.50 x 9.40mm |
Dimensions in.: 3.750 x 1.400 x 0.370in |
Package: 3714 VIA |
View Details | ||
| Part Number: | Input (V): 270.0 (160.0 - 420.0) |
Output (V): 5.0 (4.0 - 5.5) |
Power (W): 250.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Board Mount Long Pin |
Temperature: -40 to 125°C |
Dimensions mm: 95.10 x 35.50 x 9.40mm |
Dimensions in.: 3.750 x 1.400 x 0.370in |
Package: 3714 VIA |
View Details | ||
| Part Number: | Input (V): 270.0 (160.0 - 420.0) |
Output (V): 5.0 (4.0 - 5.5) |
Power (W): 250.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Board Mount Long Pin |
Temperature: -55 to 125°C |
Dimensions mm: 95.10 x 35.50 x 9.40mm |
Dimensions in.: 3.750 x 1.400 x 0.370in |
Package: 3714 VIA |
View Details | ||
| Part Number: | Input (V): 270.0 (160.0 - 420.0) |
Output (V): 5.0 (4.0 - 5.5) |
Power (W): 250.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Board Mount Long Pin |
Temperature: -20 to 125°C |
Dimensions mm: 95.10 x 35.50 x 9.40mm |
Dimensions in.: 3.750 x 1.400 x 0.370in |
Package: 3714 VIA |
View Details | ||
| Part Number: | Input (V): 270.0 (160.0 - 420.0) |
Output (V): 5.0 (4.0 - 5.5) |
Power (W): 250.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Chassis Mount |
Temperature: -20 to 125°C |
Dimensions mm: 95.10 x 35.50 x 9.40mm |
Dimensions in.: 3.750 x 1.400 x 0.370in |
Package: 3714 VIA |
View Details | ||
| Part Number: | Input (V): 270.0 (160.0 - 420.0) |
Output (V): 5.0 (4.0 - 5.5) |
Power (W): 250.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Board Mount Short Pin |
Temperature: -55 to 125°C |
Dimensions mm: 95.10 x 35.50 x 9.40mm |
Dimensions in.: 3.750 x 1.400 x 0.370in |
Package: 3714 VIA |
View Details | ||
| Part Number: | Input (V): 270.0 (160.0 - 420.0) |
Output (V): 5.0 (4.0 - 5.5) |
Power (W): 250.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Board Mount Short Pin |
Temperature: -40 to 125°C |
Dimensions mm: 95.10 x 35.50 x 9.40mm |
Dimensions in.: 3.750 x 1.400 x 0.370in |
Package: 3714 VIA |
View Details | ||
| Part Number: | Input (V): 270.0 (160.0 - 420.0) |
Output (V): 5.0 (4.0 - 5.5) |
Power (W): 250.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Chassis Mount |
Temperature: -55 to 125°C |
Dimensions mm: 95.10 x 35.50 x 9.40mm |
Dimensions in.: 3.750 x 1.400 x 0.370in |
Package: 3714 VIA |
View Details | ||
| Part Number: | Input (V): 270.0 (160.0 - 420.0) |
Output (V): 5.0 (4.0 - 5.5) |
Power (W): 250.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
Package: 4623 ChiP |
View Details | ||
| Part Number: | Input (V): 270.0 (160.0 - 420.0) |
Output (V): 5.0 (4.0 - 5.5) |
Power (W): 250.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
Package: 4623 ChiP |
View Details | ||
| Part Number: | Input (V): 270.0 (160.0 - 420.0) |
Output (V): 5.0 (4.0 - 5.5) |
Power (W): 250.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
Package: 4623 ChiP |
View Details | ||
| Part Number: | Input (V): 270.0 (160.0 - 420.0) |
Output (V): 5.0 (4.0 - 5.5) |
Power (W): 250.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
Package: 4623 ChiP |
View Details | ||
| Part Number: | Input (V): 270.0 (160.0 - 420.0) |
Output (V): 12.0 (7.2 - 13.2) |
Power (W): 500.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Chassis Mount |
Temperature: -40 to 125°C |
Dimensions mm: 95.10 x 35.50 x 9.40mm |
Dimensions in.: 3.750 x 1.400 x 0.370in |
Package: 3714 VIA |
View Details | ||
| Part Number: | Input (V): 270.0 (160.0 - 420.0) |
Output (V): 12.0 (7.2 - 13.2) |
Power (W): 500.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Chassis Mount |
Temperature: -55 to 125°C |
Dimensions mm: 95.10 x 35.50 x 9.40mm |
Dimensions in.: 3.750 x 1.400 x 0.370in |
Package: 3714 VIA |
View Details | ||
| Part Number: | Input (V): 270.0 (160.0 - 420.0) |
Output (V): 12.0 (7.2 - 13.2) |
Power (W): 500.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Board Mount Long Pin |
Temperature: -20 to 125°C |
Dimensions mm: 95.10 x 35.50 x 9.40mm |
Dimensions in.: 3.750 x 1.400 x 0.370in |
Package: 3714 VIA |
View Details | ||
| Part Number: | Input (V): 270.0 (160.0 - 420.0) |
Output (V): 12.0 (7.2 - 13.2) |
Power (W): 500.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Board Mount Long Pin |
Temperature: -40 to 125°C |
Dimensions mm: 95.10 x 35.50 x 9.40mm |
Dimensions in.: 3.750 x 1.400 x 0.370in |
Package: 3714 VIA |
View Details | ||
| Part Number: | Input (V): 270.0 (160.0 - 420.0) |
Output (V): 12.0 (7.2 - 13.2) |
Power (W): 500.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Board Mount Short Pin |
Temperature: -40 to 125°C |
Dimensions mm: 95.10 x 35.50 x 9.40mm |
Dimensions in.: 3.750 x 1.400 x 0.370in |
Package: 3714 VIA |
View Details | ||
| Part Number: | Input (V): 270.0 (160.0 - 420.0) |
Output (V): 12.0 (7.2 - 13.2) |
Power (W): 500.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Chassis Mount |
Temperature: -20 to 125°C |
Dimensions mm: 95.10 x 35.50 x 9.40mm |
Dimensions in.: 3.750 x 1.400 x 0.370in |
Package: 3714 VIA |
View Details | ||
| Part Number: | Input (V): 270.0 (160.0 - 420.0) |
Output (V): 12.0 (7.2 - 13.2) |
Power (W): 500.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Board Mount Short Pin |
Temperature: -55 to 125°C |
Dimensions mm: 95.10 x 35.50 x 9.40mm |
Dimensions in.: 3.750 x 1.400 x 0.370in |
Package: 3714 VIA |
View Details | ||
| Part Number: | Input (V): 270.0 (160.0 - 420.0) |
Output (V): 12.0 (7.2 - 13.2) |
Power (W): 500.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Board Mount Long Pin |
Temperature: -55 to 125°C |
Dimensions mm: 95.10 x 35.50 x 9.40mm |
Dimensions in.: 3.750 x 1.400 x 0.370in |
Package: 3714 VIA |
View Details | ||
| Part Number: | Input (V): 270.0 (160.0 - 420.0) |
Output (V): 12.0 (7.2 - 13.2) |
Power (W): 500.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Board Mount Short Pin |
Temperature: -20 to 125°C |
Dimensions mm: 95.10 x 35.50 x 9.40mm |
Dimensions in.: 3.750 x 1.400 x 0.370in |
Package: 3714 VIA |
View Details | ||
| Part Number: | Input (V): 270.0 (160.0 - 420.0) |
Output (V): 12.0 (7.2 - 13.2) |
Power (W): 500.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
Package: 4623 ChiP |
View Details | ||
| Part Number: | Input (V): 270.0 (160.0 - 420.0) |
Output (V): 12.0 (7.2 - 13.2) |
Power (W): 500.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
Package: 4623 ChiP |
View Details | ||
| Part Number: | Input (V): 270.0 (160.0 - 420.0) |
Output (V): 12.0 (7.2 - 13.2) |
Power (W): 500.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
Package: 4623 ChiP |
View Details | ||
| Part Number: | Input (V): 270.0 (160.0 - 420.0) |
Output (V): 12.0 (7.2 - 13.2) |
Power (W): 500.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
Package: 4623 ChiP |
View Details | ||
| Part Number: | Input (V): 270.0 (160.0 - 420.0) |
Output (V): 15.0 (9.0 - 16.5) |
Power (W): 500.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Chassis Mount |
Temperature: -55 to 125°C |
Dimensions mm: 95.10 x 35.50 x 9.40mm |
Dimensions in.: 3.750 x 1.400 x 0.370in |
Package: 3714 VIA |
View Details | ||
| Part Number: | Input (V): 270.0 (160.0 - 420.0) |
Output (V): 15.0 (9.0 - 16.5) |
Power (W): 500.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
Package: 4623 ChiP |
View Details | ||
| Part Number: | Input (V): 270.0 (160.0 - 420.0) |
Output (V): 15.0 (9.0 - 16.5) |
Power (W): 500.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
Package: 4623 ChiP |
View Details | ||
| Part Number: | Input (V): 270.0 (160.0 - 420.0) |
Output (V): 15.0 (9.0 - 16.5) |
Power (W): 500.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
Package: 4623 ChiP |
View Details | ||
| Part Number: | Input (V): 270.0 (160.0 - 420.0) |
Output (V): 15.0 (9.0 - 16.5) |
Power (W): 500.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
Package: 4623 ChiP |
View Details | ||
| Part Number: | Input (V): 270.0 (160.0 - 420.0) |
Output (V): 24.0 (14.4 - 26.4) |
Power (W): 500.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Chassis Mount |
Temperature: -40 to 125°C |
Dimensions mm: 95.10 x 35.50 x 9.40mm |
Dimensions in.: 3.750 x 1.400 x 0.370in |
Package: 3714 VIA |
View Details | ||
| Part Number: | Input (V): 270.0 (160.0 - 420.0) |
Output (V): 24.0 (14.4 - 26.4) |
Power (W): 500.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Board Mount Short Pin |
Temperature: -20 to 125°C |
Dimensions mm: 95.10 x 35.50 x 9.40mm |
Dimensions in.: 3.750 x 1.400 x 0.370in |
Package: 3714 VIA |
View Details | ||
| Part Number: | Input (V): 270.0 (160.0 - 420.0) |
Output (V): 24.0 (14.4 - 26.4) |
Power (W): 500.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Board Mount Long Pin |
Temperature: -55 to 125°C |
Dimensions mm: 95.10 x 35.50 x 9.40mm |
Dimensions in.: 3.750 x 1.400 x 0.370in |
Package: 3714 VIA |
View Details | ||
| Part Number: | Input (V): 270.0 (160.0 - 420.0) |
Output (V): 24.0 (14.4 - 26.4) |
Power (W): 500.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Board Mount Short Pin |
Temperature: -55 to 125°C |
Dimensions mm: 95.10 x 35.50 x 9.40mm |
Dimensions in.: 3.750 x 1.400 x 0.370in |
Package: 3714 VIA |
View Details | ||
| Part Number: | Input (V): 270.0 (160.0 - 420.0) |
Output (V): 24.0 (14.4 - 26.4) |
Power (W): 500.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Chassis Mount |
Temperature: -20 to 125°C |
Dimensions mm: 95.10 x 35.50 x 9.40mm |
Dimensions in.: 3.750 x 1.400 x 0.370in |
Package: 3714 VIA |
View Details | ||
| Part Number: | Input (V): 270.0 (160.0 - 420.0) |
Output (V): 24.0 (14.4 - 26.4) |
Power (W): 500.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Board Mount Long Pin |
Temperature: -40 to 125°C |
Dimensions mm: 95.10 x 35.50 x 9.40mm |
Dimensions in.: 3.750 x 1.400 x 0.370in |
Package: 3714 VIA |
View Details | ||
| Part Number: | Input (V): 270.0 (160.0 - 420.0) |
Output (V): 24.0 (14.4 - 26.4) |
Power (W): 500.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Board Mount Short Pin |
Temperature: -40 to 125°C |
Dimensions mm: 95.10 x 35.50 x 9.40mm |
Dimensions in.: 3.750 x 1.400 x 0.370in |
Package: 3714 VIA |
View Details | ||
| Part Number: | Input (V): 270.0 (160.0 - 420.0) |
Output (V): 24.0 (14.4 - 26.4) |
Power (W): 500.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Board Mount Long Pin |
Temperature: -20 to 125°C |
Dimensions mm: 95.10 x 35.50 x 9.40mm |
Dimensions in.: 3.750 x 1.400 x 0.370in |
Package: 3714 VIA |
View Details | ||
| Part Number: | Input (V): 270.0 (160.0 - 420.0) |
Output (V): 24.0 (14.4 - 26.4) |
Power (W): 500.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Chassis Mount |
Temperature: -55 to 125°C |
Dimensions mm: 95.10 x 35.50 x 9.40mm |
Dimensions in.: 3.750 x 1.400 x 0.370in |
Package: 3714 VIA |
View Details | ||
| Part Number: | Input (V): 270.0 (160.0 - 420.0) |
Output (V): 24.0 (14.4 - 26.4) |
Power (W): 500.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
Package: 4623 ChiP |
View Details | ||
| Part Number: | Input (V): 270.0 (160.0 - 420.0) |
Output (V): 24.0 (14.4 - 26.4) |
Power (W): 500.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
Package: 4623 ChiP |
View Details | ||
| Part Number: | Input (V): 270.0 (160.0 - 420.0) |
Output (V): 24.0 (14.4 - 26.4) |
Power (W): 500.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
Package: 4623 ChiP |
View Details | ||
| Part Number: | Input (V): 270.0 (160.0 - 420.0) |
Output (V): 24.0 (14.4 - 26.4) |
Power (W): 500.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
Package: 4623 ChiP |
View Details | ||
| Part Number: | Input (V): 270.0 (160.0 - 420.0) |
Output (V): 28.0 (16.8 - 30.8) |
Power (W): 500.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Board Mount Short Pin |
Temperature: -20 to 125°C |
Dimensions mm: 95.10 x 35.50 x 9.40mm |
Dimensions in.: 3.750 x 1.400 x 0.370in |
Package: 3714 VIA |
View Details | ||
| Part Number: | Input (V): 270.0 (160.0 - 420.0) |
Output (V): 28.0 (16.8 - 30.8) |
Power (W): 500.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Board Mount Long Pin |
Temperature: -20 to 125°C |
Dimensions mm: 95.10 x 35.50 x 9.40mm |
Dimensions in.: 3.750 x 1.400 x 0.370in |
Package: 3714 VIA |
View Details | ||
| Part Number: | Input (V): 270.0 (160.0 - 420.0) |
Output (V): 28.0 (16.8 - 30.8) |
Power (W): 500.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Board Mount Short Pin |
Temperature: -55 to 125°C |
Dimensions mm: 95.10 x 35.50 x 9.40mm |
Dimensions in.: 3.750 x 1.400 x 0.370in |
Package: 3714 VIA |
View Details | ||
| Part Number: | Input (V): 270.0 (160.0 - 420.0) |
Output (V): 28.0 (16.8 - 30.8) |
Power (W): 500.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Board Mount Short Pin |
Temperature: -40 to 125°C |
Dimensions mm: 95.10 x 35.50 x 9.40mm |
Dimensions in.: 3.750 x 1.400 x 0.370in |
Package: 3714 VIA |
View Details | ||
| Part Number: | Input (V): 270.0 (160.0 - 420.0) |
Output (V): 28.0 (16.8 - 30.8) |
Power (W): 500.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Board Mount Long Pin |
Temperature: -40 to 125°C |
Dimensions mm: 95.10 x 35.50 x 9.40mm |
Dimensions in.: 3.750 x 1.400 x 0.370in |
Package: 3714 VIA |
View Details | ||
| Part Number: | Input (V): 270.0 (160.0 - 420.0) |
Output (V): 28.0 (16.8 - 30.8) |
Power (W): 500.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Chassis Mount |
Temperature: -40 to 125°C |
Dimensions mm: 95.10 x 35.50 x 9.40mm |
Dimensions in.: 3.750 x 1.400 x 0.370in |
Package: 3714 VIA |
View Details | ||
| Part Number: | Input (V): 270.0 (160.0 - 420.0) |
Output (V): 28.0 (16.8 - 30.8) |
Power (W): 500.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Chassis Mount |
Temperature: -20 to 125°C |
Dimensions mm: 95.10 x 35.50 x 9.40mm |
Dimensions in.: 3.750 x 1.400 x 0.370in |
Package: 3714 VIA |
View Details | ||
| Part Number: | Input (V): 270.0 (160.0 - 420.0) |
Output (V): 28.0 (16.8 - 30.8) |
Power (W): 500.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Board Mount Long Pin |
Temperature: -55 to 125°C |
Dimensions mm: 95.10 x 35.50 x 9.40mm |
Dimensions in.: 3.750 x 1.400 x 0.370in |
Package: 3714 VIA |
View Details | ||
| Part Number: | Input (V): 270.0 (160.0 - 420.0) |
Output (V): 28.0 (16.8 - 30.8) |
Power (W): 500.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Chassis Mount |
Temperature: -55 to 125°C |
Dimensions mm: 95.10 x 35.50 x 9.40mm |
Dimensions in.: 3.750 x 1.400 x 0.370in |
Package: 3714 VIA |
View Details | ||
| Part Number: | Input (V): 270.0 (160.0 - 420.0) |
Output (V): 28.0 (16.8 - 30.8) |
Power (W): 500.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
Package: 4623 ChiP |
View Details | ||
| Part Number: | Input (V): 270.0 (160.0 - 420.0) |
Output (V): 28.0 (16.8 - 30.8) |
Power (W): 500.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
Package: 4623 ChiP |
View Details | ||
| Part Number: | Input (V): 270.0 (160.0 - 420.0) |
Output (V): 28.0 (16.8 - 30.8) |
Power (W): 500.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
Package: 4623 ChiP |
View Details | ||
| Part Number: | Input (V): 270.0 (160.0 - 420.0) |
Output (V): 28.0 (16.8 - 30.8) |
Power (W): 500.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
Package: 4623 ChiP |
View Details | ||
| Part Number: | Input (V): 270.0 (160.0 - 420.0) |
Output (V): 28.0 (16.8 - 30.8) |
Power (W): 500.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
Package: 4623 ChiP |
View Details | ||
| Part Number: | Input (V): 270.0 (160.0 - 420.0) |
Output (V): 48.0 (28.8 - 52.8) |
Power (W): 500.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
Package: 4623 ChiP |
View Details | ||
| Part Number: | Input (V): 270.0 (160.0 - 420.0) |
Output (V): 48.0 (28.8 - 52.8) |
Power (W): 500.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
Package: 4623 ChiP |
View Details | ||
| Part Number: | Input (V): 270.0 (160.0 - 420.0) |
Output (V): 48.0 (28.8 - 52.8) |
Power (W): 500.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
Package: 4623 ChiP |
View Details | ||
| Part Number: | Input (V): 270.0 (160.0 - 420.0) |
Output (V): 48.0 (28.8 - 52.8) |
Power (W): 500.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
Package: 4623 ChiP |
View Details | ||
| Part Number: | Input (V): 270.0 (180.0 - 400.0) |
Output (V): 28.0 (22.0 - 36.0) |
Power (W): 1300.0 |
Control Interface: PM Bus |
Optimized for: Array |
Mounting: Chassis Mount |
Temperature: -40 to 125°C |
Dimensions mm: 141.43 x 35.54 x 9.40mm |
Dimensions in.: 5.570 x 1.400 x 0.370in |
Package: 5614 VIA |
View Details | ||
| Part Number: | Input (V): 270.0 (180.0 - 400.0) |
Output (V): 28.0 (22.0 - 36.0) |
Power (W): 1300.0 |
Control Interface: PM Bus |
Optimized for: Array |
Mounting: Board Mount Short Pin |
Temperature: -40 to 125°C |
Dimensions mm: 141.43 x 35.54 x 9.40mm |
Dimensions in.: 5.570 x 1.400 x 0.370in |
Package: 5614 VIA |
View Details | ||
| Part Number: | Input (V): 270.0 (180.0 - 400.0) |
Output (V): 28.0 (22.0 - 36.0) |
Power (W): 1300.0 |
Control Interface: PM Bus |
Optimized for: Array |
Mounting: Board Mount Long Pin |
Temperature: -40 to 125°C |
Dimensions mm: 141.43 x 35.54 x 9.40mm |
Dimensions in.: 5.570 x 1.400 x 0.370in |
Package: 5614 VIA |
View Details | ||
| Part Number: | Input (V): 270.0 (180.0 - 400.0) |
Output (V): 28.0 (22.0 - 36.0) |
Power (W): 1300.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Chassis Mount |
Temperature: -40 to 125°C |
Dimensions mm: 141.43 x 35.54 x 9.40mm |
Dimensions in.: 5.570 x 1.400 x 0.370in |
Package: 5614 VIA |
View Details | ||
| Part Number: | Input (V): 275.0 (120.0 - 420.0) |
Output (V): 3.3 (2.97 - 3.63) |
Power (W): 110.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
Package: 4623 ChiP |
View Details | ||
| Part Number: | Input (V): 275.0 (120.0 - 420.0) |
Output (V): 3.3 (2.97 - 3.63) |
Power (W): 110.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
Package: 4623 ChiP |
View Details | ||
| Part Number: | Input (V): 275.0 (120.0 - 420.0) |
Output (V): 3.3 (2.97 - 3.63) |
Power (W): 110.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
Package: 4623 ChiP |
View Details | ||
| Part Number: | Input (V): 275.0 (120.0 - 420.0) |
Output (V): 3.3 (2.97 - 3.63) |
Power (W): 110.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
Package: 4623 ChiP |
View Details | ||
| Part Number: | Input (V): 275.0 (120.0 - 420.0) |
Output (V): 5.0 (3.5 - 5.5) |
Power (W): 190.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
Package: 4623 ChiP |
View Details | ||
| Part Number: | Input (V): 275.0 (120.0 - 420.0) |
Output (V): 5.0 (3.5 - 5.5) |
Power (W): 190.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
Package: 4623 ChiP |
View Details | ||
| Part Number: | Input (V): 275.0 (120.0 - 420.0) |
Output (V): 5.0 (3.5 - 5.5) |
Power (W): 190.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
Package: 4623 ChiP |
View Details | ||
| Part Number: | Input (V): 275.0 (120.0 - 420.0) |
Output (V): 5.0 (3.5 - 5.5) |
Power (W): 190.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
Package: 4623 ChiP |
View Details | ||
| Part Number: | Input (V): 275.0 (120.0 - 420.0) |
Output (V): 12.0 (7.2 - 13.2) |
Power (W): 375.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
Package: 4623 ChiP |
View Details | ||
| Part Number: | Input (V): 275.0 (120.0 - 420.0) |
Output (V): 12.0 (7.2 - 13.2) |
Power (W): 375.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
Package: 4623 ChiP |
View Details | ||
| Part Number: | Input (V): 275.0 (120.0 - 420.0) |
Output (V): 12.0 (7.2 - 13.2) |
Power (W): 375.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
Package: 4623 ChiP |
View Details | ||
| Part Number: | Input (V): 275.0 (120.0 - 420.0) |
Output (V): 12.0 (7.2 - 13.2) |
Power (W): 375.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
Package: 4623 ChiP |
View Details | ||
| Part Number: | Input (V): 275.0 (120.0 - 420.0) |
Output (V): 15.0 (9.0 - 16.5) |
Power (W): 375.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
Package: 4623 ChiP |
View Details | ||
| Part Number: | Input (V): 275.0 (120.0 - 420.0) |
Output (V): 15.0 (9.0 - 16.5) |
Power (W): 375.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
Package: 4623 ChiP |
View Details | ||
| Part Number: | Input (V): 275.0 (120.0 - 420.0) |
Output (V): 15.0 (9.0 - 16.5) |
Power (W): 375.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
Package: 4623 ChiP |
View Details | ||
| Part Number: | Input (V): 275.0 (120.0 - 420.0) |
Output (V): 15.0 (9.0 - 16.5) |
Power (W): 375.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
Package: 4623 ChiP |
View Details | ||
| Part Number: | Input (V): 275.0 (120.0 - 420.0) |
Output (V): 24.0 (14.4 - 26.4) |
Power (W): 375.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
Package: 4623 ChiP |
View Details | ||
| Part Number: | Input (V): 275.0 (120.0 - 420.0) |
Output (V): 24.0 (14.4 - 26.4) |
Power (W): 375.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
Package: 4623 ChiP |
View Details | ||
| Part Number: | Input (V): 275.0 (120.0 - 420.0) |
Output (V): 24.0 (14.4 - 26.4) |
Power (W): 375.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
Package: 4623 ChiP |
View Details | ||
| Part Number: | Input (V): 275.0 (120.0 - 420.0) |
Output (V): 24.0 (14.4 - 26.4) |
Power (W): 375.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
Package: 4623 ChiP |
View Details | ||
| Part Number: | Input (V): 275.0 (120.0 - 420.0) |
Output (V): 28.0 (16.8 - 30.8) |
Power (W): 375.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
Package: 4623 ChiP |
View Details | ||
| Part Number: | Input (V): 275.0 (120.0 - 420.0) |
Output (V): 28.0 (16.8 - 30.8) |
Power (W): 375.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
Package: 4623 ChiP |
View Details | ||
| Part Number: | Input (V): 275.0 (120.0 - 420.0) |
Output (V): 28.0 (16.8 - 30.8) |
Power (W): 375.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
Package: 4623 ChiP |
View Details | ||
| Part Number: | Input (V): 275.0 (120.0 - 420.0) |
Output (V): 28.0 (16.8 - 30.8) |
Power (W): 375.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
Package: 4623 ChiP |
View Details | ||
| Part Number: | Input (V): 275.0 (120.0 - 420.0) |
Output (V): 48.0 (28.8 - 52.8) |
Power (W): 375.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
Package: 4623 ChiP |
View Details | ||
| Part Number: | Input (V): 275.0 (120.0 - 420.0) |
Output (V): 48.0 (28.8 - 52.8) |
Power (W): 375.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
Package: 4623 ChiP |
View Details | ||
| Part Number: | Input (V): 275.0 (120.0 - 420.0) |
Output (V): 48.0 (28.8 - 52.8) |
Power (W): 375.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
Package: 4623 ChiP |
View Details | ||
| Part Number: | Input (V): 275.0 (120.0 - 420.0) |
Output (V): 48.0 (28.8 - 52.8) |
Power (W): 375.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
Package: 4623 ChiP |
View Details | ||
| Part Number: | Input (V): 290.0 (200.0 - 378.0) |
Output (V): 13.8 (11.5 - 15.5) |
Power (W): 600.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
Package: 4623 ChiP |
View Details | ||
| Part Number: | Input (V): 290.0 (200.0 - 378.0) |
Output (V): 13.8 (11.5 - 15.5) |
Power (W): 600.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
Package: 4623 ChiP |
View Details | ||
| Part Number: | Input (V): 300.0 (180.0 - 420.0) |
Output (V): 12.0 (7.2 - 13.2) |
Power (W): 400.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Board Mount Short Pin |
Temperature: -20 to 125°C |
Dimensions mm: 95.10 x 35.50 x 9.40mm |
Dimensions in.: 3.750 x 1.400 x 0.370in |
Package: 3714 VIA |
View Details | ||
| Part Number: | Input (V): 300.0 (180.0 - 420.0) |
Output (V): 12.0 (7.2 - 13.2) |
Power (W): 400.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Board Mount Long Pin |
Temperature: -20 to 125°C |
Dimensions mm: 95.10 x 35.50 x 9.40mm |
Dimensions in.: 3.750 x 1.400 x 0.370in |
Package: 3714 VIA |
View Details | ||
| Part Number: | Input (V): 300.0 (180.0 - 420.0) |
Output (V): 12.0 (7.2 - 13.2) |
Power (W): 400.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Board Mount Short Pin |
Temperature: -40 to 125°C |
Dimensions mm: 95.10 x 35.50 x 9.40mm |
Dimensions in.: 3.750 x 1.400 x 0.370in |
Package: 3714 VIA |
View Details | ||
| Part Number: | Input (V): 300.0 (180.0 - 420.0) |
Output (V): 12.0 (7.2 - 13.2) |
Power (W): 400.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Chassis Mount |
Temperature: -40 to 125°C |
Dimensions mm: 95.10 x 35.50 x 9.40mm |
Dimensions in.: 3.750 x 1.400 x 0.370in |
Package: 3714 VIA |
View Details | ||
| Part Number: | Input (V): 300.0 (180.0 - 420.0) |
Output (V): 12.0 (7.2 - 13.2) |
Power (W): 400.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Board Mount Long Pin |
Temperature: -40 to 125°C |
Dimensions mm: 95.10 x 35.50 x 9.40mm |
Dimensions in.: 3.750 x 1.400 x 0.370in |
Package: 3714 VIA |
View Details | ||
| Part Number: | Input (V): 300.0 (180.0 - 420.0) |
Output (V): 12.0 (7.2 - 13.2) |
Power (W): 400.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Chassis Mount |
Temperature: -20 to 125°C |
Dimensions mm: 95.10 x 35.50 x 9.40mm |
Dimensions in.: 3.750 x 1.400 x 0.370in |
Package: 3714 VIA |
View Details | ||
| Part Number: | Input (V): 300.0 (180.0 - 420.0) |
Output (V): 12.0 (7.2 - 13.2) |
Power (W): 400.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
Package: 4623 ChiP |
View Details | ||
| Part Number: | Input (V): 300.0 (180.0 - 420.0) |
Output (V): 12.0 (7.2 - 13.2) |
Power (W): 400.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
Package: 4623 ChiP |
View Details | ||
| Part Number: | Input (V): 300.0 (180.0 - 420.0) |
Output (V): 12.0 (7.2 - 13.2) |
Power (W): 400.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
Package: 4623 ChiP |
View Details | ||
| Part Number: | Input (V): 300.0 (180.0 - 420.0) |
Output (V): 12.0 (7.2 - 13.2) |
Power (W): 400.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
Package: 4623 ChiP |
View Details | ||
| Part Number: | Input (V): 300.0 (180.0 - 420.0) |
Output (V): 12.0 (7.2 - 13.2) |
Power (W): 400.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
Package: 4623 ChiP |
View Details | ||
| Part Number: | Input (V): 300.0 (200.0 - 420.0) |
Output (V): 13.8 (8.28 - 15.18) |
Power (W): 500.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
Package: 4623 ChiP |
View Details | ||
| Part Number: | Input (V): 300.0 (200.0 - 420.0) |
Output (V): 13.8 (8.28 - 15.18) |
Power (W): 500.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
Package: 4623 ChiP |
View Details | ||
| Part Number: | Input (V): 300.0 (200.0 - 420.0) |
Output (V): 24.0 (21.6 - 26.4) |
Power (W): 600.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Board Mount Long Pin |
Temperature: -40 to 125°C |
Dimensions mm: 95.10 x 35.50 x 9.40mm |
Dimensions in.: 3.750 x 1.400 x 0.370in |
Package: 3714 VIA |
View Details | ||
| Part Number: | Input (V): 300.0 (200.0 - 420.0) |
Output (V): 24.0 (21.6 - 26.4) |
Power (W): 600.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Chassis Mount |
Temperature: -40 to 125°C |
Dimensions mm: 95.10 x 35.50 x 9.40mm |
Dimensions in.: 3.750 x 1.400 x 0.370in |
Package: 3714 VIA |
View Details | ||
| Part Number: | Input (V): 300.0 (200.0 - 420.0) |
Output (V): 24.0 (21.6 - 26.4) |
Power (W): 600.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Board Mount Short Pin |
Temperature: -20 to 125°C |
Dimensions mm: 95.10 x 35.50 x 9.40mm |
Dimensions in.: 3.750 x 1.400 x 0.370in |
Package: 3714 VIA |
View Details | ||
| Part Number: | Input (V): 300.0 (200.0 - 420.0) |
Output (V): 24.0 (21.6 - 26.4) |
Power (W): 600.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Chassis Mount |
Temperature: -20 to 125°C |
Dimensions mm: 95.10 x 35.50 x 9.40mm |
Dimensions in.: 3.750 x 1.400 x 0.370in |
Package: 3714 VIA |
View Details | ||
| Part Number: | Input (V): 300.0 (200.0 - 420.0) |
Output (V): 24.0 (21.6 - 26.4) |
Power (W): 600.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Board Mount Long Pin |
Temperature: -20 to 125°C |
Dimensions mm: 95.10 x 35.50 x 9.40mm |
Dimensions in.: 3.750 x 1.400 x 0.370in |
Package: 3714 VIA |
View Details | ||
| Part Number: | Input (V): 300.0 (200.0 - 420.0) |
Output (V): 24.0 (21.6 - 26.4) |
Power (W): 600.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Board Mount Short Pin |
Temperature: -40 to 125°C |
Dimensions mm: 95.10 x 35.50 x 9.40mm |
Dimensions in.: 3.750 x 1.400 x 0.370in |
Package: 3714 VIA |
View Details | ||
| Part Number: | Input (V): 300.0 (200.0 - 420.0) |
Output (V): 24.0 (21.6 - 26.4) |
Power (W): 600.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
Package: 4623 ChiP |
View Details | ||
| Part Number: | Input (V): 300.0 (200.0 - 420.0) |
Output (V): 24.0 (21.6 - 26.4) |
Power (W): 600.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
Package: 4623 ChiP |
View Details | ||
| Part Number: | Input (V): 300.0 (200.0 - 420.0) |
Output (V): 24.0 (21.6 - 26.4) |
Power (W): 600.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
Package: 4623 ChiP |
View Details | ||
| Part Number: | Input (V): 300.0 (200.0 - 420.0) |
Output (V): 24.0 (21.6 - 26.4) |
Power (W): 600.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
Package: 4623 ChiP |
View Details | ||
| Part Number: | Input (V): 300.0 (200.0 - 420.0) |
Output (V): 28.0 (16.8 - 30.8) |
Power (W): 500.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Chassis Mount |
Temperature: -40 to 125°C |
Dimensions mm: 95.10 x 35.50 x 9.40mm |
Dimensions in.: 3.750 x 1.400 x 0.370in |
Package: 3714 VIA |
View Details | ||
| Part Number: | Input (V): 300.0 (200.0 - 420.0) |
Output (V): 28.0 (16.8 - 30.8) |
Power (W): 500.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Board Mount Long Pin |
Temperature: -20 to 125°C |
Dimensions mm: 95.10 x 35.50 x 9.40mm |
Dimensions in.: 3.750 x 1.400 x 0.370in |
Package: 3714 VIA |
View Details | ||
| Part Number: | Input (V): 300.0 (200.0 - 420.0) |
Output (V): 28.0 (16.8 - 30.8) |
Power (W): 500.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Board Mount Short Pin |
Temperature: -20 to 125°C |
Dimensions mm: 95.10 x 35.50 x 9.40mm |
Dimensions in.: 3.750 x 1.400 x 0.370in |
Package: 3714 VIA |
View Details | ||
| Part Number: | Input (V): 300.0 (200.0 - 420.0) |
Output (V): 28.0 (16.8 - 30.8) |
Power (W): 500.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Chassis Mount |
Temperature: -20 to 125°C |
Dimensions mm: 95.10 x 35.50 x 9.40mm |
Dimensions in.: 3.750 x 1.400 x 0.370in |
Package: 3714 VIA |
View Details | ||
| Part Number: | Input (V): 300.0 (200.0 - 420.0) |
Output (V): 28.0 (16.8 - 30.8) |
Power (W): 500.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Board Mount Long Pin |
Temperature: -40 to 125°C |
Dimensions mm: 95.10 x 35.50 x 9.40mm |
Dimensions in.: 3.750 x 1.400 x 0.370in |
Package: 3714 VIA |
View Details | ||
| Part Number: | Input (V): 300.0 (200.0 - 420.0) |
Output (V): 28.0 (16.8 - 30.8) |
Power (W): 500.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Board Mount Short Pin |
Temperature: -40 to 125°C |
Dimensions mm: 95.10 x 35.50 x 9.40mm |
Dimensions in.: 3.750 x 1.400 x 0.370in |
Package: 3714 VIA |
View Details | ||
| Part Number: | Input (V): 300.0 (200.0 - 420.0) |
Output (V): 28.0 (16.8 - 30.8) |
Power (W): 500.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
Package: 4623 ChiP |
View Details | ||
| Part Number: | Input (V): 300.0 (200.0 - 420.0) |
Output (V): 28.0 (16.8 - 30.8) |
Power (W): 500.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
Package: 4623 ChiP |
View Details | ||
| Part Number: | Input (V): 300.0 (200.0 - 420.0) |
Output (V): 28.0 (16.8 - 30.8) |
Power (W): 500.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
Package: 4623 ChiP |
View Details | ||
| Part Number: | Input (V): 300.0 (200.0 - 420.0) |
Output (V): 28.0 (16.8 - 30.8) |
Power (W): 500.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
Package: 4623 ChiP |
View Details | ||
| Part Number: | Input (V): 300.0 (200.0 - 420.0) |
Output (V): 48.0 (28.8 - 52.8) |
Power (W): 500.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Board Mount Long Pin |
Temperature: -20 to 125°C |
Dimensions mm: 95.10 x 35.50 x 9.40mm |
Dimensions in.: 3.750 x 1.400 x 0.370in |
Package: 3714 VIA |
View Details | ||
| Part Number: | Input (V): 300.0 (200.0 - 420.0) |
Output (V): 48.0 (28.8 - 52.8) |
Power (W): 500.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Board Mount Short Pin |
Temperature: -40 to 125°C |
Dimensions mm: 95.10 x 35.50 x 9.40mm |
Dimensions in.: 3.750 x 1.400 x 0.370in |
Package: 3714 VIA |
View Details | ||
| Part Number: | Input (V): 300.0 (200.0 - 420.0) |
Output (V): 48.0 (28.8 - 52.8) |
Power (W): 500.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Board Mount Short Pin |
Temperature: -20 to 125°C |
Dimensions mm: 95.10 x 35.50 x 9.40mm |
Dimensions in.: 3.750 x 1.400 x 0.370in |
Package: 3714 VIA |
View Details | ||
| Part Number: | Input (V): 300.0 (200.0 - 420.0) |
Output (V): 48.0 (28.8 - 52.8) |
Power (W): 500.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Board Mount Long Pin |
Temperature: -40 to 125°C |
Dimensions mm: 95.10 x 35.50 x 9.40mm |
Dimensions in.: 3.750 x 1.400 x 0.370in |
Package: 3714 VIA |
View Details | ||
| Part Number: | Input (V): 300.0 (200.0 - 420.0) |
Output (V): 48.0 (28.8 - 52.8) |
Power (W): 500.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Chassis Mount |
Temperature: -40 to 125°C |
Dimensions mm: 95.10 x 35.50 x 9.40mm |
Dimensions in.: 3.750 x 1.400 x 0.370in |
Package: 3714 VIA |
View Details | ||
| Part Number: | Input (V): 300.0 (200.0 - 420.0) |
Output (V): 48.0 (28.8 - 52.8) |
Power (W): 500.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Chassis Mount |
Temperature: -20 to 125°C |
Dimensions mm: 95.10 x 35.50 x 9.40mm |
Dimensions in.: 3.750 x 1.400 x 0.370in |
Package: 3714 VIA |
View Details | ||
| Part Number: | Input (V): 300.0 (200.0 - 420.0) |
Output (V): 48.0 (28.8 - 52.8) |
Power (W): 500.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
Package: 4623 ChiP |
View Details | ||
| Part Number: | Input (V): 300.0 (200.0 - 420.0) |
Output (V): 48.0 (28.8 - 52.8) |
Power (W): 500.0 |
Control Interface: Analog |
Optimized for: Standalone |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
Package: 4623 ChiP |
View Details | ||
| Part Number: | Input (V): 300.0 (200.0 - 420.0) |
Output (V): 48.0 (28.8 - 52.8) |
Power (W): 500.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -55 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
Package: 4623 ChiP |
View Details | ||
| Part Number: | Input (V): 300.0 (200.0 - 420.0) |
Output (V): 48.0 (28.8 - 52.8) |
Power (W): 500.0 |
Control Interface: Analog |
Optimized for: Array |
Mounting: Through Hole |
Temperature: -40 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
Package: 4623 ChiP |
View Details | ||
Power System Designer
Quick product searchWatch demo video
Output
Min output:
Minimum output:
Nom output:
Nominal output:
Max output:
Maximum output:
Features and benefits
Features and benefits
Up to 1300W, 46.4A continuous
Up to 96% peak efficiency
Up to 1244W/in3
OV, OC, UV, short circuit & thermal protection
Watch the Digi-key video describing how the DCM provides all the necessary performance and features to create smaller, lighter and less costly power systems
promotion-component
Building a smarter ultra-wide DC-DC converter solution with multiple parts
Get Whitepaper
Resources
Resources for the design engineer
Lightning Motorcycles accelerates into the EV racing record books
Lightning Motorcycle has built the fastest electric motorcycle on the planet
Autonomous Security Robots patrol with super-human acuity and detection prowess
Public safety risks are on the rise and better robotic surveillance and interdiction is the answer
Modular power delivery networks for UAVs
The key challenge we see facing engineers today is the demand for smaller, lighter-weight designs that deliver higher power
- AN:029 Single DCM as an Isolated, Regulated DC-DC Converter
- AN:030 Parallel DCMs
- AN:031 - Through-Hole ChiP Package Soldering Guidelines
- AN:035 - Achieving High Accuracy Voltage (or Current) Regulation with the DCM Up to ± 1% regulation
- AN:036 - Recommendations for Maximum Compressive Force of Heat Sinks
- AN:039 - Thermal Management for VIA and ChiP Modules
- AN:401 – PCB Mount VIA Soldering Guidelines
- Power solution reduces downtime
- More patrolling, less recharging for security robots
- Improving the ergonomics of hand-held tools with medical robots
- Wide input voltage facilitates contactless power solution for overhead gantry robots
- Fixed-winged HALE UAV gets an 11kW power supply the size of a tablet computer
- Instrumentation for ore prospecting allows reliable operation in a tough environment
- Energy consumption and running costs were reduced in this weaving loom with the supply’s improved power factor
- 100% reliable backhaul communications uses an array with a footprint of just 52.97cm2
- Powering high-tech 4K cameras overcomes size, weight and EMI requirements
- A complete N+1 solution maintains uptime for network security AC-DC power supply
- Power sharing among converters simplifies remote upgrading of optical packet transport systems
- Scalable, low-weight DC-DC solution for high-capacitive loads in airborne radar
- Multiple power supplies paralleled together provided 9kW high-output power
- A wide-input voltage range allows full utilization of the battery, which extended the range of the UAVs
- Avionic equipment operates simultaneously from multiple power sources in extreme temps without fans
- Supply voltage for the RF amplifier is well regulated during frequency-hopping, providing secure communication in portable radios
- Minimal distortion and power supply noise helps achieve maximum range in portable ground radar
- Enhanced onboard satellite voice and data communications takes advantage of maximized power amplifier efficiency
- Dual-sided cooling of power supplies on vertically-mounted racks improves thermal performance for sub-combat control
- Optimize battery charging and control motor start-up allows longer time in flight for inspection UAVs
- Lightweight and small-sized power solution for thermal imaging camera supports increasing power and complexity
- Different power requirements are handled so that UAVs adapt to different required payloads
- Image stability for the gimbal system improves vehicle-mounted optical sights
- 5kW tethered UAVs fly higher and longer using increased voltage on the tether
- Industrial flow meters are more accurate while working over wider flow ranges
- Scalable power solution matches specific power levels for various machines in optical sorting
- Powering a smart control upgrade minimizes wasted head in hydraulic pumps
- Decreased weight and size of the power source enables the payload increase of tethered robots
- Minimizing the weight, size and transmission losses due to heavy cabling gives tethered UAVs better performance
- A third more power in just 20% of the space for vehicle GPS applications
4623 ChiP
- cURus – UL 60950-1, CSA 60950-1 »
- cTÜVus – EN 60950-1, UL 60950-1, CSA 60950-1
- cTÜVus – EN 62368, UL 62368, CSA 62368
- CE Mark – Low Voltage Directive (2014/35/EU) and RoHS Recast Directive (2011/65/EU)
- CB Certificate – IEC 60950-1
- CB Certificate – IEC 62368
- cURus – UL 60950-1, CSA 60950-1 »
- cTÜVus – EN 62368, UL 62368, CSA 62368
- CE Mark – Low Voltage Directive (2014/35/EU) and RoHS Recast Directive (2011/65/EU)
- CB Certificate – IEC 62368
- cURus – UL 60950-1, CSA 60950-1
- cTÜVus – EN 62368-1, UL 62368-1, CSA 62368-1
- CE Mark – Low Voltage Directive (2014/35/EU) and RoHS Recast Directive (2011/65/EU)
- CB Certificate – IEC 62368-1
- cURus – UL 60950-1, CSA 60950-1
- cTÜVus – EN 62368-1, UL 62368-1, CSA 62368-1
- CE Mark – Low Voltage Directive (2014/35/EU) and RoHS Recast Directive (2011/65/EU)
- CB Certificate – IEC 62368-1
- cTÜVus – EN 62368, UL 62368, CSA 62368
- CE Mark – Low Voltage Directive (2014/35/EU) and RoHS Recast Directive (2011/65/EU)
- CB Certificate – IEC 62368
- CSA 62368
For California residents see information regarding California Proposition 65
- 2322 ChiP Through-Hole Product Outline Drawing
PDF DXF - 3623 ChiP Through-Hole Product Outline Drawing
PDF DXF - 4623 ChiP Through-Hole Product Outline Drawing
PDF DXF - 3414 and 3714 VIA DCM Chassis Mount with Comm Outline Drawing
PDF DXF - 3414 and 3714 VIA DCM Through-Hole with Comm Outline Drawing
PDF DXF - 5614 VIA DCM Chassis Mount with Comm Outline Drawing
PDF DXF - 5614 VIA DCM Through-Hole with Comm Outline Drawing
PDF DXF
- 2322 ChiP Through-Hole Product 3-D Model Drawing
IGS STP - 3623 ChiP Through-Hole Product 3-D Model Drawing
IGS STP - 4623 ChiP Through-Hole Product 3-D Model Drawing
IGS STP - 3414 VIA DCM Chassis Mount with Comm Outline Drawing
IGS STP - 3414 VIA DCM Through-Hole Short Pin with Comm Outline Drawing
IGS STP - 3414 VIA DCM Through-Hole Long Pin with Comm Outline Drawing
IGS STP - 3714 VIA DCM Chassis Mount with Comm Outline Drawing
IGS STP - 3714 VIA DCM Through-Hole Short Pin with Comm Outline Drawing
IGS STP - 3714 VIA DCM Through-Hole Long Pin with Comm Outline Drawing
IGS STP - 5614 VIA DCM Chassis Mount with Comm Outline Drawing
IGS STP - 5614 VIA DCM Through-Hole Short Pin with Comm Outline Drawing
IGS STP - 5614 VIA DCM Through-Hole Long Pin with Comm Outline Drawing
IGS STP
Promo Component
Get more documents, videos and case studies in the resource library for engineers
Related Products
Related Products
12V, 24V or 48V direct to point-of-load regulators
Rugged high power converters for 28V and 270V line inputs
